Fiber Laser Marking/Engraving Machine BL7000 series
Features
- CNC control and maintenance-free fiber laser
- Maximum working area by using of axes, up to. 730 x 730 mm
- Optional turntable for semi-automatic solutions. Loading/unloading times are reduced to almost zero.
- The integrated control panel is ergonomically integrated into the cabin and allows intuitive operation of the machine.
- Fully encapsulated machine, comply with laser protection class 1, no additional cost for laser protection.
Application
- Widely used in Electronic components, Glasses, watch and clock, Plastic tool, Medical device, IC card, Kitchen and bathroom industry etc.
Specifications
| Laser type | Ytterbium fiber laser |
| Wavelength | 1064 nm |
| Pulse repetition frequency | 20 – 200 kHz |
| Power | 10 – 100 W |
| Marking area | max. 730 x 730 mm |
| Control | CNC control |
| System software | Windows 7 |
| Measurements | 1600 x 1320 x 1992 mm (L x W x H) |
| Network connection | Yes |
Samples
2D deep logo engraving
3D deep engraving
nameplate marking
marking on anodized material
marking on brass
marking on adaptor
marking on small tool
marking on electronic product
marking on plastic cup
plastic layer ablation
Materials
| Material | Engrave |
| Stainless | √ |
| Coated Metals | √ |
| Anodized Aluminum | |
| Brass | √ |
| Copper | √ |
| Gold | √ |
| Silver | √ |
| Titanium | √ |
| Bare Metals | √ |
| Ruber | √ |
| PP | √ |
| PS | √ |
| PP | √ |
| ABS | √ |
| PVC | √ |
| PE | √ |
| Acrylic | |
| MDF | |
| Wood | |
| Granite | |
| Marble | |
| Brick | |
| Glass | |
| Fiber Glass | |
| Crystal | √ |
| Ceramic | √ |
| Diamond | √ |
| Gemstone | √ |
| Cloth | √ |
| Leather | √ |
| Fiber | √ |
| Carbon Fiber | √ |
